Size |
Ply Rating |
Speed index |
Load Index |
Standard Rim |
Max.Load(kg) |
Inflation Pressure(kPa) |
Inflated Section Width(mm) |
Overall Diameter,Inflated(mm) |
Pattern Depth(mm) |
| 11R22.5 | 14 | L | 144/142 | 8.25 | 2800/2650 | 720/720 | 279 | 1050 | 15 |
| 11R22.5 | 16 | L | 146/143 | 8.25 | 3000/2725 | 830/830 | 279 | 1050 | 15 |
| 295/75R22.5 | 14 | L | 144/141 | 9.00 | 2800/2575 | 760/760 | 298 | 1014 | 15 |
| 295/75R22.5 | 16 | L | 146/143 | 9.00 | 3000/2725 | 830/830 | 298 | 1014 | 15 |
| 11R24.5 | 14 | L | 146/143 | 8.25 | 3000/2725 | 720/720 | 279 | 1104 | 15 |
| 11R24.5 | 16 | L | 149/146 | 8.25 | 3250/3000 | 830/830 | 279 | 1104 | 15 |
| 285/75R24.5 | 14 | L | 144/141 | 8.25 | 2800/2575 | 760/760 | 283 | 1050 | 15 |
| 285/75R24.5 | 16 | L | 147/144 | 8.25 | 3075/2800 | 830/830 | 283 | 1050 | 15 |
